MSI · Motherboard
Part #PROB650M-P
MSI Pro B650M-P D5 Board
audio chipset: Realtek ALC897audio channels: 7.1memory max: 256memory slots: 4
Хамгийн бага үнэ
Байна₮ 420,000
Дэлгүүрүүд
NewTech.mnХямд
₮ 420,000
Байна
Үнийн түүх
Тех. үзүүлэлт
| audio chipset | Realtek ALC897 |
| audio channels | 7.1 |
| memory max | 256 |
| memory slots | 4 |
| memory ram type | DDR5 |
| socket | AM5 |
| chipset | AMD B650 |
| m2 slots | key: M, size: 2280/2260, interface: PCIe 4.0 x4, key: M, size: 2280/2260, interface: PCIe 4.0 x4 |
| pcie slots | gen: 4.0, lanes: 16, quantity: 1, gen: 3.0, lanes: 1, quantity: 2 |
| fan headers pump | 1 |
| fan headers cpu fan | 1 |
| fan headers case fan | 3 |
| form factor | Micro ATX |
| rgb headers argb 5v | 2 |
| rgb headers rgb 12v | 2 |
| usb headers usb 2 0 | 2 |
| usb headers usb 3 2 gen 1 | 1 |
| usb headers usb 3 2 gen 2 | 1 |
| raid support | true |
| bios features flashback | true |
| other headers com port | 1 |
| storage devices sata 6 gb s | 4 |
| back panel ports | 1 x Flash BIOS button, 1 x DisplayPort 1.4, 1 x HDMI 2.1 port, 1 x VGA port, 2 x USB 3.2 Gen 2 10Gbps Type-A ports, 2 x USB 3.2 Gen 1 5Gbps Type-A ports, 4 x USB 2.0 Type-A ports, 1 x PS/2 keyboard/mouse combo port, 1 x 2.5Gbps LAN (RJ45) jack, 3 x Audio jacks |
| onboard ethernet | speed: 2.5 Gb/s, controller: Realtek 8125BG |
| power connectors cpu power | 8-pin |
| power connectors main power | 24-pin |
| front panel headers hdd led | true |
| front panel headers power led | true |
| front panel headers power button | true |
| front panel headers reset button | true |
